3D Computed tomography (CT) Machine
Shimadzu Xseeker 8000 This bench-top X-ray computed tomography (CT) system is equipped with a high-output X-ray generator and a high-resolution flat panel detector. Despite its compact size, it has a high X-ray output of 160 kV, enabling clear observations of molded plastic parts as well as die cast parts.
You can start your first CT scan with the push of a button. 12 seconds is all it takes to acquire, compute & generate the CT data. It is the perfect blend of affordability and functionality.
Shimadzu SMX-100CT is a CT system capable of performing high-magnification 3D observations of resins, medicines, bones, and other soft materials. It is equipped with a sealed tube type microfocus X-ray generator with a maximum output of 100 kV, and a high-sensitivity image intensifier.
The interface provided is capable of easily observing the internal 3D structure of samples. Furthermore, clear, high-magnification CT images are obtained faster and more clearly thanks to the high-performance computing system HPC inspeXio.
Shimadzu SMX-225CT FPD HR Plus is a high-performance microfocus X-ray CT system equipped with a Shimadzu microfocus X-ray generator and a large high-resolution flat panel detector.
The large detection area, data input capacity equivalent to 14 megapixels, and a further improved high-output microfocus X-ray generator enable CT images with a large field-of-view, high resolution, and high contrast levels that overturn the conventional assumption that high-output systems cannot provide adequate contrast for soft materials.
To correspond to the higher detector resolution, the HPC inspeXio high-performance computing system achieves even faster speeds.
Therefore, this single system can be used for researching, developing, or inspecting a wide variety of samples, from composite materials (such as, GFRP and CFRTP materials still being researched today) to large aluminum die cast parts.
Shimadzu XDimensus 300 is a dimensional X-ray CT system capable of measuring the 3D internal and external geometry of sample interiors. With a sphere distance error of (3.8 + L/50) μm, providing the world’s highest level of accuracy assurance.
It features a large-scale, high-resolution flat panel detector, which provides a wide field of view at excellent resolution, Shimadzu's proprietary new X-ray generator, with approximately three times the X-ray generating efficiency of our previous models, and new software, which provides excellent operation. It also features an air conditioning unit to maintain a consistent temperature inside the instrument, a frame that provides high geometric stability, and an ultra-high-accuracy sample positioning stage. As a result, it provides a level of dimensional measurement accuracy impossible with conventional observation X-ray CT systems.
Shimadzu is offering this new, unprecedented system for dimensional measurements, including the interior and exterior of industrial goods such as plastic molded parts and aluminum die cast part
Xctal 5000 is a new X-ray CT system that creates images of X-ray phase shifts. In addition to the X-ray absorption information detected by conventional X-ray CT systems, this system can detect X-ray scattering and refraction information. This provides observations of fine structure across a wide field of view, and high-contrast observations of samples with no absorption differences.
This is useful for research and development of fiber reinforced resins, composite materials, and biomaterials, which are advancing through research.
